Syllabus
- Overview of Redhawk and Basics of Power , EM, IR
- Average Power Calculation and Static Analysis
- IP Modelling Techniques in Redhawk
- APL Characterisation
- Dynamic Analysis Vectorless Single Cycle and Multi Cycle Flows
- Dynamic Vectored Analysis
- Redhawk Signal EM
- Low Power Design Analysis
- Setup of Redhawk
Phase#1:
- Overview of Redhawk.
- Labs: Understanding of Input files of Redhawk, Setting up of Redhawk Env.
- Basics of Power, EM, IR.
- Data Preparation of Redhawk- Generation of Collaterals from ICC
- Understanding Volcano Design.
- IP Modelling Techniques.
- Analyzing of APL using utilities Aqua and ACE.
- Sanity Checks of all Inputs Colleterals.
- Grid Weakness Checks, Resistance Extraction.
- Performing PG Resistance Analysis – effective resistance of Instances, Pin Path Resistance Checks
- Missing Vias Checks
- Analysing Shorts
- Disconnected Instances
- Connectivity Checks
- Average Power Calculation
- Static Analysis Theory
- Redhawk Static IR/EM Flow
- Setting Up of GSR for Static Run.
- Creation of Command run file.
- Power Calculation in Static Analysis using Toggle rate.
- Power Calculation in Static Analysis using BPFS.
- Doing experiments with BPFS.
- Exploration of Redhawk TCL Commands for advanced Debugging of IR Drop.
- Creation of Custom lib’s for Missing PG Arcs.
- Exploration of Redhawk Explorer.
- Exploration of Power Maps.
- Package and PAD Constraints.
- Results Exploration and Debugging.
- Debugging EM Violations.
- Analyzing Hot spots.
- Analysis Battery Currents and Demands Currents.
- Dynamic Vectorless Analysis
- Redhawk Dynamic Flow
- Setting Up of GSR for Static Run.
- Creation of Command run file.
- Plotting Instance current
- Min, Max, Avg DVD in Timing Window and min DVD in Whole Simulation Cycle.
- Analysis of Switches and its equivalent reports
- Wire IR Drops
- Exploration of DVD Histograms.
- Plotting Instance Voltage Waveform.
- Plotting Switching Histograms.
- Analyzing Switching events
- Decap Density Maps
- Dynamic Voltage Drop Movie.
- Analysis Dynamic Reports
- Design Weakness Checks
- Pad Current Checks
- Decap Efficiency Checks
- Simultaneous Switching Checks
- Frequency Domain based Demand Current Checks
- Voltage Domain based Demand Current Checks
- Cross Probing Violations in Redhawk GUI
- Hotspot Analysis Summary
- DVD Check – Instance Level Debug
- Short Path Tracing of Instances
- Power EM Checks
- Multicycle Vectorless Analysis
- Labs:
- Correlation between Single Cycle and Multicycle analysis
- Cycle based Switching
- All labs on Dynamic Vectorless will be applicable to Multicycle
- Running Redhawk Power IR/EM on Volcano or ORCA_TOP
- Running Redhawk on Power IR/EM Ansys Design.
- Assignments
1. Static EM/IR Analysis.(6hrs)
2. Dynamic EM/IR Vectorless Analysis Single Cycle.(6hrs)
3. Dynamic EM/IR Vectorless Analysis Multi Cycle.(6 hrs)
4. Dynamic Vectored Analysis Worst Power Cycle.(6hrs)
5. Dynamic Vectored Analysis Worst dpdt Cycle.(6 hrs)
6. Signal EM Analysis.(3hrs)
7. Low Power Design Analysis(6 hrs)
Course Overview
Course Overview
Redhawk IR drop and power integrity analysis training The RedHawk IR Drop and Power Integrity Analysis Training (35 hours) provides engineers with in-depth knowledge of IR drop analysis, power integrity checks, electro migration (EM), thermal reliability, and ESD sign-off. Through hands-on sessions with Ansys RedHawk, participants learn how to perform static and dynamic IR drop analysis, apply sign-off methodologies, and ensure power-efficient, high-performance SoC design. This program prepares engineers to confidently handle industry-standard RedHawk flows for advanced semiconductor technologies.
