Synthesis and STA Training is a 4 months course, provides the participants with in-depth exposure to both Synthesis and complete Timing SignOff strategies for successful and confident Tape-Out of the Design to the Semiconductor Fabrication House. STA Training: Timing is the heartbeat of any chip. Thorough understanding of timing concepts and development of timing constraints are given through this STA Training, especially when it comes to Ultra Deep Sub-Micron Technologies such as 28nm to 5nm. There are multiple parameters that decide how the timing of a chip would be functioning, like Transition times of Clock phases and Data Path signals, Process and Voltage and Temperature (PVT) variations, Crosstalk noise affecting functionality of the chip, Crosstalk Delay affecting timing of the chip—which will be covered in greater detail in this STA Training. Other topics such as Advanced OCV, requirement of Clock path tweaking to meet desired frequency of the chip will be discussed extensively. Pessimism inclusion when design is tapped-out has been a norm to avoid any Silicon surprises, but for higher frequency designs on lower technology nodes, pessimism beyond a limit could be an over-do—in which case pessimism-Removal is done through Path-Based Analysis rather than Graph based Analysis. This topic is covered with fine clarity in this STA Training. Above all, the fundamental part of setup and hold time fixing covering the above points are the key aspects of this STA Training. Candidates will get access to tools both at the institute and have the option to connect to servers from home using Secure VPN to work on new Sign Off projects hands-on. Fixing of timing violations based on Sign-Off analysis for Multi Mode Multi Corner through ECOs would be across the breadth of this STA Training. Objective of this STA training is to shape graduating Bachelor’s and Master’s degree students as well as Physical Design Engineers to explore opportunities in Block Level as well as Full Chip STA. Synthesis Training: Synthesis training includes all the aspects starting from HDL modelling, Synthesis flow, Constraints, analysing and debugging the results, optimization techniques, report generation and hands-on projects to understand the Synthesis complete flow. Below are the STA Training topics. SignOff STA Training topics : - Fundamental Setup and Hold Timing Checks - Timing Arcs across Design Instances - Stage Delay covering Cell Delay and Net Delay - Asynchronous Flop, recovery and removal checks - Cross Clock Timing Analysis - Interface Timing Analysis (between reg and IO) - Clock group based timing analysis - Crosstalk Delay and Crosstalk Noise - Advanced On Chip Variation, CPPR - Multi-Mode Multi-Corner timing analysis - Graph Based and Path based analysis - Timing DRC – Transition, Capacitance, Fanout fixes. - Clock path ECO and Data path ECO - Constraint Development specifically Interface timing Synthesis Training covers the aspect of converting the design in the form of RTL into Technology mapped netlist. Synthesis is an algorithm-intensive task consisting of many stages within it requiring various inputs in order to produce a functionally correct netlist. The main part of Synthesis Training consists of reading in the design, converting RTL to Boolean equations through elaboration, then converting the Boolean equations to Generic Mapped Cells and then technology mapped cells from library, setting constraints, optimizing the design, analyzing the results and saving the design database for Placement and Routing stage to take on. Candidates who are interested in exploring opportunities in Synthesis and Front-end STA can undergo this in-depth Synthesis training to get good understanding of RTL constructs, Gate level Netlist, Constraint Development, Latch based designs, pipe lining and re-timing, basic Scan stitching, Setup timing closure, Topography based logic restructuring, Wire Load Models, Logical Equivalence Checks. Hierarchical Synthesis is another key feature covered in this Synthesis Training. Cadence Implementation Suite for Synthesis (as RTL Compiler / Genus) would be used in this Synthesis Training program. Candidates would get hands-on work on two full designs. Synthesis Training Topics covered: - Introduction to synthesis - Reading RTL in HDL form, dotlibs, SDC - Different types of RTL constructs - Analyzing dotlib files - Elaboration and Generic Synthesis - Understanding DesignWare components and Logical Operators - Clock gating insertion for reducing Dynamic power post CTS - Creating list of dont_touch and dont_use cells - Technology mapped Synthesis and optimization - Scan Insertion techniques - Checking Design for number of instances, area estimate - Check clock reaching clock pins of flops, unblocked flops - Time borrowing concepts for latch based paths - Leakage variants of standard cells LVT, RVT, HVT - Constraints on logical hierarchy boundaries - Setting Max Transition, Max Capacitance, Max Fanout - Push down and pull up timing constraints - Master clocks and generated clocks in design - Estimating uncertainty values, input and output delays in SDC - False path, Multi cycle path exceptions. - Disabling timing loops in design - Logical Equivalence Checking fundamentals (Top level and Hierarchical) - Hand off database to PnR
